The machine that we designed is a milling installation which is used for the machining of the popularized western-style wooden window. By applying this kind of knowledge, we could reduce the production costs of those products as western-style wooden window and enhance its competitive power.
Through the analysis of both the domestic and the foreign tenoners and on the basis of the consideration of its production costs, we have designed this kind of equipment which could meet the need for the joint of general tenon need raw materials and have made approve-ments to its tool system. Through this change, we have made its tool system more applicable for the joint of those products in smaller section size. The tool’s primary shaft works in higher rotational speed and withstands certain torque. We have carried out the force analysis in this article to make sure its security and have made checkouts to its accessorial parts, such as transmission belt and transmission shaft and so on. Through the analysis of the spring force, we uses the spring to compact in the lumber raw material jig system to make sure that the lumber raw materials could clamp smoothly in the situation which uses the minimum forces.
Combined from infact of product, this topic is set up both for the design of the key equipments which are used for the machining of this small materials and to make approvements to the existing tenoners so as to reduce the costs of the connect production line and to make this technique popular. With regard to our middle and small carpentry enterprise's production modification and technical innovation, this design has quite a vital significance.
